RQGZ1-N
5705.021.205

Description


1/2" NPT FLEXAquick® straight strain relief connector, for 21.2 mm OD conduit, outer thread

Clamps 7 - 12.0 mm cables

IP 66 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • resistant to oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® conduits

Specifications

Connector Thread:
1/2" NPT
Sealing Level:
IP66
Colour:
Black
Weight:
0.022
Package quantity:
10

Dimensions:
φ I:
12.00
φ B:
29.50
C:
15.00
D:
73.00
Conduit OD:
21.2 mm

Certifications

CSA 22.2
CSA 22.2
# 227.3-05

Alternate SKU Numbers

5705-021-205 | 5705021205 | 5705 021 205 | 5705_021_205 | 5705/021/205 | 5705,021,205 | 5705+021+205
