RQGZ-N 1 1/4'' NPT FLEXAquick® Strain Relief Connector for 42.5 mm OD conduit
5704.042.217
Description
1 1/4" NPT FLEXAquick® straight strain-relief connector for 42.5 mm OD conduit, outer thread
Cable clamping range: 24 - 32.0 mm
IP 68 / IP 69K sealing level
-40ºC to +115ºC
Innovative feature:
- Built-in wire & cable strain-relief system with sealing grommet
- The conduit end of the fitting features a Quick "on" assembly, Quick "off" disassembly via the unique FLEXAquick® built-in release clip system. NO tools required!
Material:
- plastic PA 6 polyamide, nylon
- VO acc. to UL94
Properties:
- resistant to oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- excellent for high mechanical stress
- impact-resistant
Use with ROHRflex® corrugated plastic conduits
Quick Links to other Products:
Specifications
Connector Thread:
1 1/4" NPT
Sealing Level:
IP68
Colour:
Black
Weight:
0.089 kg
Package quantity:
10
Dimensions:
φ I:
32.00
φ B:
52.00
C:
19.00
D:
100.00
Conduit OD:
42.5 mm
Certifications

CSA 22.2
# 227.3-05

UL 1696
#E86359

E162 & 662
SMP800C


45545-2
HL2 Rated

NFF 16-
101/102 I3



Alternate SKU Numbers
5704-042-217 | 5704042217 | 5704 042 217 | 5704_042_217 | 5704/042/217 | 5704,042,217 | 5704+042+217
